Paper and othe
r Media
Xerox 4112/4127 Copier/Printer
8-13
User Guide
Loading T
a
b P
aper
into T
ra
y
8 (P
ost-P
rocess Inserter)
1.
Hold the center of the
paper guides and slid
e them to the desired paper size
.
2.
If the paper is preprint
ed, load the paper with the print
ed side f
acing up and with the tab
side to be
f
ed first.
tab ed
ge
224
226
