Addendum
Xerox 4112/4127 Copier/Printer 14-17
User Guide
Interface Module (IM)
The Interface Module (IM) is an optional finishing accessory that is used in conjunction with
other optional finishing accessories, such as the High Capacity Stacker (HCS), the Standard
Finisher, or the Optional Booklet Maker Finisher. The Interface Module (IM) acts as a
communication device and paper path between the printer and an optional finishing device
such the High Capacity Stacker.
Control Panel
The Control Panel consists of the following:
1. Auto Curl button: This button selects the Auto Decurl function.
2. Manual Curl Up button: This button selects the three values of manual up curl.
3. Manual Curl Down button: This button selects the three values of manual down curl.
4. Auto Curl indicator: This indicates the that the Auto Curl Mode is selected.
5. Curl Up/Down Indicators: These indicate the amount of manual curl (up or down) that is
selected.
Interface Module
1
2
3
4
5
