Xerox 8830 - REP 10.3 Fuser Triac

REP 10.3 Fuser Triac
Parts List on PL 1.2
WARNING
Switch off the Main Power Switch. Disconnect the
Power Cord.
Removal
1. Remove the two Right Side Covers.
2. (Figure 1): Remove the Fuser Triac.
Remove the
Fuser Triac
Replacement
1. Cover the entire surface where the Fuser Triac
mounts to the frame with a film of thermal
compound or install a new Thermal Insulator.
Remove the
screws (2)
Insulator
Figure 1. Removing the Fuser Triac
REP 10.3
1/98
4-88
8830
