PQ16 Skewed Image
Symptom/ check
The image is skewed to one side on the print
because the media is skewed.
Probable Cause
1. Media is not loaded correctly.
2. Media Transport.
3. Defective or contaminated rollers in the
media feed area
4. Incorrect registration roller nip
5. Obstruction in media path
Corrective Action
1. Load the media correctly and instruct the
operator on loading the media correctly.
2. Ensure that the Media Transport gap (ADJ
8.4) is set correctly.
3. Check the rollers and other components in
the media feed area.
4, Clean or replace the registration roller (PL
8.2).
5. Check media path.
PQ16 Skewed Image
1/98
3-24
8830
