PQ14 Misregistration
Symptom/ check
The registration of the image on the prints is
incorrect from top to bottom or side to side.
Probable Cause
1. Incorrect registration adjustment
2. Damaged or worn components in the media
feeding area
3. Defective registration sensor
4. Incorrect registration roller nip
5. Incorrectly loaded media
Corrective Action
1. Adjust Lead Edge Registration (ADJ 8.2).
2. Check the components for damage or wear.
3. Refer to BSD 8.1 and check the operation of
the registration sensor. Replace the sensor if
required (REP 8.8).
4. Clean or replace the registration roller (PL
8.2).
5. Instruct the operator on loading the media
correctly.
PQ 14 Misregistration
1/98
3-22
8830
