PQ12 Finger Marks
Symptom/ check
Toner marks on the lead edge or trail edge of
the print.
Probable Cause
1. Defective or dirty transfer/detack Corotron
2. Cleaner Seal
3. Web Oiler
4. Turnaround Baffle
5. Heat Roll
6. Fabric Guide
Corrective Action
1A. Clean or replace the Corotron wire
(PL 9.4).
1B. Perform GP1, HVPS Checkout Procedure.
2. Check / clean as required. (PL 9.5A)
3. Check / replace (REP 10.9)
4. Ensure that the baffle is free of
contamination (PL 8.2).
5. Check/replace (REP'10,2)
6. Check/replace (REP 8.9)
PQ12 Finger Marks
1/98
3-20
8830
