Xerox 8830 Service Manual

Message Display Entry Chart
MESSAGE DISPLAYED
PRINTER IS WARMING UP
(Continuously displayed)
ADJUSTING THE PRINT QUALITY
(Continuously displayed)
PLEASE CLOSE THE MEDIA
DRAWER X (Refer to Note)
PLEASE CLOSE THE CUT SHEET
FEED SHELF
PLEASE CLOSE THE FRONT DOOR
PLEASE CLOSE THE TOP DOOR
PLEASE CLOSE THE CUTTER
DRAWER
NVM FAULT CALL FOR
ASSISTANCE
Re-feed Roll 1
Re-feed Roll 2
Re-feed Roll 3
Flashing 1,2, 3,4, 5,6 or 7
UNABLE TO CALIBRATE TONER
SENSOR
TONER FAULT CALL FOR
ASSISTANCE
CAUSE
No fuser heat
Toner dispense problem
Drawer X read switch is open.
Cut sheet feed shelf interlock
switch (S29) is open.
Front door interlock switch
(S21)is open.
Top cover interlock switch
(S26) Is open.
Cutter cover interlock switch
(S1) is open.
Corrupted data in NVM.
Re-feed roll 1 problem.
Re-feed roll 2 problem.
Re-feed roll 3 problem.
Copier failed power on self-
test.
The sensor did not calibrate
when the code [0921-6] was
entered.
Excessive toner sensed
problem.
. CLEARANCE PROCEDURE
...
...
Refer to the display on the control panel and follow the
clearance procedure.
Refer to the display on the control panel and follow the
clearance procedure.
Refer to the display on the control panel and follow the
clearance procedure.
Refer to the display on the control panel and follow the
clearance procedure.
Refer to the display on the control panel and follow the
clearance procedure.
Press power off (0) then power on (1). If problem persist run
diagnostic program [0363] or [0360]. If problem persist replace
the Control EPROMS.
Re-feed the media. If necessary, press power off (0) then
power on (1).
Re-feed the -media. If necessary, press power off (0) then
power on (1).
Re-feed the media. If necessary, press power off (0) then
power on (1).
Press power off (0) then power on (1). If problem persists, go
to RAP OF2.
Press power off (0), then power on (1). If problem persists, go
to RAP LL.91.
Press power off (0), then power on (1). If problem persists, go
to RAP LL.90.
BSD Ref
10.1
9.3
7.1
1.2
1.2
1.2
1.2
7.2
7.3
7.4
9.7
9.7
NOTE: Substitute 1,2, or 3 for X depending on which status code is displayed.
Message Display Entry Chart
1/98
1-18
8830
