PQ15 Residual Image
Symptom/ check
This is an image that is repeated on the same
print or consecutive prints. The image can
either be a ghosting of the original Image or a
toner image. The repeated image is usually
spaced 10.38 inches (265 mm) from the original
image.
Perform Panic Stop / Image on Drum procedure
(Section 6), and examine the drum for the
defect.
Probable Cause
1. The Cleaner Blade makes poor contact with
drum.
2. Defective erase lamp
3. Contaminated drum
Corrective Action
1. Replace the Cleaner Blade (REP 9.4).
2. Refer to BSD 9.6 and check the erase lamp.
Replace the lamp if necessary (PL 9.5A).
3. Replace the drum (REP 9.3).
8830
1/98
3-23
PQ 15 Residual Image
