REP 8.5 Pressure Plates
Parts List on PL 10.3
WARNING
Switch off the Main Power Switch. Disconnect the
Power Cord.
NOTE: The art used for this procedure was
developed for previous products and may not match
the 8830 configuration exactly.
Removal
1. Latch the Xerographic Module at the Service
Position (REP 9.2).
2. Remove the Media Transport Assembly (REP
8.1).
3. Remove the Fabric Guide (REP 8.9).
CAUTION
Be sure to push the Buckle Switch Actuator down
while starting to remove the Upper Pressure Plate in
order to prevent damage to the actuator.
4. (Figure 1): Remove the Upper and Lower
Pressure Plates.
1
Push the Buckle Switch
Actuator down (not
shown)
Remove the Upper Pressure
Plate
Figure 1. Removing the Pressure Plates
8830
1/98
4-23
REP 8.5
