PL 15.1 MISCELLANEOUS ELECTRICAL CONNECTORS AND FAS-
TENERS
ITEM PART
2.
1
2
3
3a
3b
30
DESCRIPTION
CONTACT SOCKET
(20-26 AWG)
(TO BE AVAILABLE
AT LATER DATE)
CONTACT PIN
(20-26 AWG)
(TO BE AVAILABLE
AT LATER DATE)
WIRE AND CONNECTOR
REPAIR KIT
(TO BE AVAILABLE
AT LATER DATE)
SOCKET WIRE (10/KIT)
CONNECTOR (20/KIT)
PIN WIRE (10/KIT)
0000036A-RNO
PARTS LIST SECTION
PL 15.1
2/87
5-40
8830
