PQ5 Black Prints
Symptom/ check
The print is totally black with no image.
Probable Cause
1. Defective Charge Scorotron
2. Charge control circuit/ defective Harness
Corrective Action
1. Clean or replace the screen/pins (REP 9.8).
2. Perform GP1 HVPS Checkout Procedure.
8830
1/98
3-13
PQ4 Black Lines
