YASKAWA Z1000 User Manual

4.4 Start-Up Flowcharts
These flowcharts summarize steps required to start the drive. Use the flowcharts to determine the most appropriate start-up
method for a given application. The charts are quick references to help familiarize the user with start-up procedures.
Note: Refer to Application Selection on page 124 to set up the drive using one of the Application Presets.
Flowchart Subchart Objective Page
A – Basic start-up procedure and motor tuning 120
–
A-1 Simple motor setup using V/f mode 121
A-2 Setting up the drive to run a permanent magnet (PM) motor 122
4.4 Start-Up Flowcharts
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
119
4
Start-Up Programming & Operation

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
