A.3 Drive Watt Loss Data
Table A.7 Watt Loss 200 V Class Three-Phase Models
Model Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
2A0011
10.6
<1>
121 28 148
2A0017
16.7
<1>
176 37 214
2A0024
24.2
<1>
280 55 335
2A0031
30.8
<1>
378 73 451
2A0046
46.2
<1>
396 86 482
2A0059
59.4
<1>
542 116 658
2A0075
74.8
<1>
557 132 688
2A0088
88
<1>
670 157 827
2A0114
114
<1>
864 200 1064
2A0143
143
<1>
1191 307 1499
2A0169
169
<1>
1447 365 1811
2A0211
211
<1>
1753 471 2224
2A0273
273
<1>
2378 625 3003
2A0343
343
<2>
1964 655 2620
2A0396
396
<2>
2435 829 3264
<1> Value assumes the carrier frequency is set to 5 kHz or less.
<2> Value assumes the carrier frequency is set to 2 kHz.
Table A.8 Watt Loss 400 V Class Three-Phase Models
Model
Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
4A0005
4.8
<1>
93 24 117
4A0008
7.6
<1>
146 33 178
4A0011
11
<1>
184 38 222
4A0014
14
<1>
231 52 283
4A0021
21
<1>
306 69 375
4A0027
27
<1>
390 85 475
4A0034
34
<1>
457 105 562
4A0040
40
<1>
558 118 677
4A0052ooB
52
<1>
584 151 734
4A0052ooA
52
<1>
463 130 594
4A0065
65
<1>
576 161 737
4A0077
77
<1>
891 225 1116
4A0096
96
<1>
1131 288 1419
4A0124
124
<1>
1581 398 1979
4A0156
156
<1>
1929 535 2464
4A0180
180
<1>
2342 621 2963
4A0240
240
<2>
2863 790 3653
4A0302
302
<2>
3278 929 4207
4A0361
361
<3>
3009 1157 4166
4A0414
414
<3>
3206 1633 4840
4A0480
480
<3>
3881 2011 5893
4A0590
590
<3>
4130 1964 6094
<1> Value assumes the carrier frequency is set to 5 kHz or less.
<2> Value assumes the carrier frequency is set to 4 kHz or less.
A.3 Drive Watt Loss Data
276
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
