Page #220 background image
5.5 Alarm Detection
u
Alarm Codes, Causes, and Possible Solutions
Alarms are drive protection functions that do not necessarily cause the drive to stop. Once the cause of an alarm is removed,
the drive will return to the same status is was before the alarm occurred.
When an alarm has been triggered, the ALM light on the HOA keypad display blinks and the alarm code display flashes. If a
multi-function output is set for an alarm (H2-oo = 10), that output terminal will be triggered.
Note:
If a multi-function output is set to close when an alarm occurs (H2-oo = 10), it will also close when maintenance periods are reached,
triggering alarms LT-1 through LT-4 (triggered only if H2-oo = 2F).
Table 5.11 Alarm Codes, Causes, and Possible Solutions
HOA Keypad Display Minor Fault Name
bb
Baseblock
Drive output interrupted as indicated by an external baseblock signal.
Cause Possible Solutions
External baseblock signal was entered via one of
the multi-function input terminals (S1 to S7)
Check external sequence and baseblock signal input timing.
HOA Keypad Display Minor Fault Name
bUS
Option Communication Error
The connection was lost after initial communication was established.
Assign a Run command frequency reference to the option.
Cause Possible Solutions
Connection is broken or master controller stopped
communicating
Check for faulty wiring.
Correct the wiring.
Check for disconnected cables and short circuits. Repair as needed.
Option is damaged If there are no problems with the wiring and the fault continues to occur, replace the option.
The option is not properly connected to the drive
The connector pins on the option are not properly lined up with the connector pins on the drive.
Reinstall the option.
A data error occurred due to noise
Check options available to minimize the effects of noise.
Take steps to counteract noise in the control circuit wiring, main circuit lines and ground wiring.
Try to reduce noise on the controller side.
Use surge absorbers on magnetic contactors or other equipment causing the disturbance.
Use recommended cables or some other type of shielded line. Ground the shield to the controller
side or on the input power side.
Separate the wiring for communication devices from the drive input power lines.
HOA Keypad Display Minor Fault Name
CALL
Serial Communication Transmission Error
Communication has not yet been established.
Cause Possible Solutions
Communications wiring is faulty, there is a short
circuit, or something is not connected properly
Check for wiring errors.
Correct the wiring.
Check for disconnected cables and short circuits. Repair as needed.
Programming error on the master side Check communications at start-up and correct programming errors.
Communications circuitry is damaged
Perform a self-diagnostics check.
If the problem continues, replace either the control board or the entire drive. For instructions on
replacing the control board, contact Yaskawa or your nearest sales representative.
Termination resistor setting is incorrect
Install a termination resistor at both ends of a communication line. Set the internal termination resistor
switch correctly on slave drives. Place DIP switch S2 to the ON position.
HOA Keypad Display Minor Fault Name
CE
MEMOBUS/Modbus Communication Error
Control data was not received correctly for two seconds.
Cause Possible Solutions
5.5 Alarm Detection
220
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
