A.1 Power Ratings
u
Three-Phase 200 V Class Drive Models 2A0011 to 2A0088
Table A.1 Power Ratings (Three-Phase 200 V Class)
Item Specification
CIMR-Zo2A
0011 0017 0024 0031 0046 0059 0075 0088
Maximum
Applicable
Motor
Capacity
<1>
HP 3 5 7.5 10 15 20 25 30
kW 2.2 3.7 5.5 7.5 11 15 18.5 22
Input
Input Current (A)
<2>
10.6 16.7 24.2 30.8 46.2 59.4 74.8 88
Rated Voltage
Rated Frequency
Three-phase 200 to 240 Vac 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Minimum Power Supply Capacity (kVA) 5 7 11 13 20 25 32 37
Output
Rated Output Capacity (kVA)
<3>
4.2 6.7 10 12 18 24 30 35
Rated Output Current (A)
10.6
<4>
16.7
<4>
24.2
<4>
30.8
<4>
46.2
<4>
59.4
<4>
74.8
<4>
88
<4>
Overload Tolerance
110% of rated output current for 60 s
140% of rated output current for 0.5 s
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage (V) Three-phase 200 to 240 V (proportional to input voltage)
Maximum Output Frequency (Hz) 240 Hz
Harmonics
Reduction
DC Link Choke Built-in
EMC Filter (IEC/EN 61800-3 Category 2) Built-in
<1> The motor capacity (HP) refers to an NEC Table 430.250 208 V motor. The rated output current of the drive output amps should be equal to or
greater than the motor current. Select the appropriate capacity drive if operating the motor continuously above motor nameplate current.
<2> Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring
connections, and power supply impedance.
<3> Rated motor capacity is calculated with a rated output voltage of 230 V.
<4> Carrier frequency is set to 5 kHz. Current derating is required to raise the carrier frequency.
A.1 Power Ratings
268
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
