C.2 Communication Specifications
BACnet specifications appear in the following table:
Item Specifications
Interface
MS-TP (Master-Slave/Token-Passing)
RS-485
Communication Parameters
Communication Speeds: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 76800 bps
Data Length: 8-bit (fixed)
Parity: Select Even, Odd, or None
Stop Bit: 1-bit (fixed)
Protocol BACnet MS-TP
Max Number of Drives 127 per MS-TP Network Segment
C.2 Communication Specifications
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
343
C
BACnet Communications

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
