6.2 Drive Options and Peripheral Devices
The following table of peripheral devices lists the names of the various accessories and options available for Yaskawa drives.
Contact Yaskawa or your Yaskawa agent to order these peripheral devices.
• Peripheral Device Selection: Refer to the Yaskawa catalog for selection and part numbers.
• Peripheral Device Installation: Refer to the corresponding option manual for installation instructions.
Table 6.1 Available Peripheral Devices
Option Model Number Description
Power Options
AC Reactor –
Protects the drive when operating from a large power supply and improves the power factor by
suppressing harmonic distortion. Highly recommended for power supplies that exceed 600 kVA.
Communication Option Cards
Modbus TCP/IP SI-EM3 Connects to a Modbus TCP/IP network.
EtherNet/IP SI-EN3 Connects to an EtherNet/IP network.
LONWORKS SI-W3 Connects to a LONWORKS network.
Interface Options
Remote Operator Cable
UWR000051, 1 m cable
UWR000052, 2 m cable
RJ-45, 8-pin straight through, UTP CAT5e, extension cable (1 m or 2 m) to connect the HOA
keypad for remote operation
USB Copy Unit JVOP-181
• Allows the user to copy and verify parameter settings between drives
• Functions as an adapter to connect the drive to a USB port on a PC
Mechanical Options
Attachment for External
Heatsink
Installation kit for mounting the drive with the heatsink outside of the panel.
IP20 NEMA 1, UL Type 1 and NEMA Type 12 attachments are available. NEMA Type 12 attachments are available only
for rev. B products or later.
Others
24 V Power Supply PS-A10LB, PS-A10HB Supplies the drive controller with 24 Vdc power during main power loss.
6.2 Drive Options and Peripheral Devices
248
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
