YASKAWA Z1000 - Ip00;Open-Type Enclosure

u
IP00/Open-Type Enclosure
n
Three-Phase AC 200 V 2A0343A, 2A0396A
A
B
C
D
K
F
G
H
I
J
E
L
M
A – Fan guard
B – Cooling fan
C – Fan bracket
D –
Circulation fan
<1>
E – Front cover
F – USB port (type-B)
G – HOA keypad
H – Drive cover
I – Terminal cover
J – Screw
K – Optional 24 V DC power supply
connector cover
L – Heatsink
M – Mounting hole
Figure 1.6 Exploded view of IP00/Open-Type Enclosure Components (2A0343A)
<1> Drive models 2A0343 and 2A0396 have a built-in circulation fan.
