YASKAWA Z1000 User Manual

u
Front Views
M
E
D
A
B
C
E
F
G
J
K
L
CIMR-Zo2A0011F
I
H
CIMR-Zo2A0075F
K
L
M
A
C
EE
D
F
B
H
J
I
G
A – Terminal TB2
B – Terminal TB5 (FE)
C – Main circuit terminal
D – EMC filter switch SW2
E – Ground terminal
F – EMC filter switch SW1
G – Terminal TB4
H – Option card connector (CN5)
I – DIP switch S2
J – Terminal TB1
K – Terminal TB3
L – Jumper switch S1
M – Jumper switch S5
Figure 1.10 Front View of Drives
1.5 Component Names
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
37
1
Receiving

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
