YASKAWA Z1000 User Manual

<1> Values shown are specific to 200 V class drives. Double the value for 400 V class drives.
<2> Parameter setting value is not reset to the default value when the drive is initialized.
<3> Default setting is dependent on parameters A1-02, Control Model Selection and o2-04, Drive Model Selection.
<4> Default setting is dependent on parameter o2-04, Drive Model Selection.
<5> When Auto-Tuning is performed, E1-13 and E1-05 will be set to the same value.
<6> Parameter ignored when E1-11 (Motor 1 Mid Output Frequency 2) and E1-12 (Motor 1 Mid Output Frequency Voltage 2) are set to 0.0.
u
E2: Motor Parameters
No.
(Addr.
Hex)
Name LCD Display Description Values Page
E2-01
(30E)
Motor Rated Current Motor Rated FLA
Sets the motor nameplate full load current in amps.
Automatically set during Auto-Tuning.
Default:
<1>
Min.: 10% of
drive rated
current
Max.: 200% of
drive rated
current
<2>
135
E2-02
(30F)
Motor Rated Slip Motor Rated Slip
Sets the motor rated slip. Automatically set during
Auto-Tuning.
Default:
<1>
Min.: 0.00 Hz
Max.: 20.00 Hz
–
E2-03
(310)
Motor No-Load Current No-Load Current
Sets the no-load current for the motor. Automatically set during
Auto-Tuning.
Default:
<1>
Min.: 0 A
Max.: E2-01
<2>
–
E2-04
(311)
Number of Motor Poles Number of Poles
Sets the number of motor poles. Automatically set during
Auto-Tuning.
Default: 4
Min.: 2
Max.: 48
–
E2-05
(312)
Motor Line-to-Line
Resistance
Term Resistance
Sets the phase-to-phase motor resistance. Automatically set
during Auto-Tuning.
Default:
<1>
Min.: 0.000 Ω
Max.: 65.000 Ω
–
E2-10
(317)
Motor Iron Loss for
Torque Compensation
Motor Iron Loss
Sets the motor iron loss.
Default:
<1>
Min.: 0 W
Max.: 65535 W
–
E2-11
(318)
Motor Rated Power Mtr Rated Power
Sets the motor rated power in kilowatts (1 HP = 0.746 kW).
Automatically set during Auto-Tuning.
Default:
<1>
Min.: 0.00 kW
Max.: 370.00 kW
135
<1> Default setting is dependent on parameter o2-04, Drive Model Selection.
<2> The number of decimal places in the parameter value depends on the drive model. This value has two decimal places (0.01 A) if the drive is set for
a maximum applicable motor capacity up to and including 11 kW, 2A0031, 4A0021 (input voltage 460 V or higher) or 4A0027 (input voltage lower
than 460 V) and one decimal place (0.1 A) if the maximum applicable motor capacity is higher than 11 kW, 2A0046, 4A0027 (input voltage 460
V or higher) or 4A0034 (input voltage lower than 460 V) .
u
E5: PM Motor Settings
No.
(Addr.
Hex)
Name LCD Display Description Values Page
E5-02
(32A)
<1>
Motor Rated Power PM Mtr Capacity
OLV/PMOLV/PM
Sets the rated capacity of the motor.
Default:
<2>
Min.: 0.10 kW
Max.: 370.00 kW
135
E5-03
(32B)
<1>
Motor Rated Current PM Mtr Rated FLA
OLV/PMOLV/PM
Sets the motor rated current.
Default:
<2>
Min: 10% of
drive rated
current
Max: 200% of
drive rated
current
<3>
136
E5-04
(32C)
<1>
Number of Motor Poles PM Motor Poles
OLV/PMOLV/PM
Sets the number of motor poles.
Default:
<2>
Min.: 2
Max.: 48
136
B.5 E: Motor Parameters
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
297
B
Parameter List

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
