YASKAWA Z1000 User Manual

C.11 BACnet Protocol Implementation Conformance Statement
Date: 1/4/2011 Vendor Name: Yaskawa America, Inc.
Product Name: AC Motor Controller Product
Model Number: CIMR-ZU□A-□□□□
Application Software Version: 1.3 / Firmware Revision: VSE90101X / BACnet Protocol Revision: 4
Product Description:
The Yaskawa Z1000 Drive and Bypass products are high performance products specifically designed for commercial building
automation applications. The Yaskawa BACnet feature connects the Z1000 Drive and Bypass products to a standard BACnet
MS/TP network. These products may be fully controlled and monitored over BACnet. All drive parameters are available for
reading and writing
BACnet Standardized Device Profile (Annex L):
□ BACnet Operator Workstation (B-OWS)
□ BACnet Building Controller (B-BC)
■ BACnet Advanced Application Controller (B-AAC)
□ BACnet Application Specific Controller (B-ASC)
□ BACnet Smart Sensor (B-SS)
□ BACnet Smart Actuator (B-SA)
List all BACnet Interoperability Building Blocks Supported (Annex K):
• Data Sharing-ReadProperty-B (DS-RP-B)
• Data Sharing-WriteProperty-B (DS-WP-B
• Data Sharing - ReadProperty Multiple - B (DS-RPM-B)
• Data Sharing - WriteProperty Multiple - B (DS-WPM-B)
• Device Management-Dynamic Device Binding-B (DM-DDB-B)
• Device Management-Dynamic Object Binding-B (DM-DOB-B)
• Device Management-DeviceCommunicationControl-B (DM-DCC-B)
• Device Management-ReinitializeDevice-B (DM-RD-B)
• Device Management-TimeSyncronization-B (DM-TS-B)
Segmentation Capability:
□ Segmented requests supported / Window Size
□ Segmented responses supported / Window Size
Standard Object Types Supported:
• Device Object
• Analog Input Object
• Analog Output Object
• Analog Value Object
• Binary Input Object
• Binary Output Object
• Binary Value Object
Data Link Layer Options:
□BACnet IP, (Annex J)
□BACnet IP, (Annex J), Foreign Device
□ISO 8802-3, Ethernet (Clause 7)
□ ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
□ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s)
■MS/TP master (Clause 9), baud rate(s): 1200, 2400, 4800, 9600, 19200, 38400, 57600, 76800, 115200
□MS/TP slave (Clause 9), baud rate(s):
C.11 BACnet Protocol Implementation Conformance Statement
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
361
C
BACnet Communications
