No.
(Addr.
Hex)
Name LCD Display Description Values Page
S3-16
(3229)
Secondary PI High
Feedback Detection
Time
PI2 High FB Tim
Sets the secondary PI high feedback detection delay time in
seconds.
Default: 1.0 s
Min.: 0.0
Max.: 25.5
–
S3-17
(322A)
Secondary PI Feedback
Detection Selection
PI2 FB Det Sel
0: PI2 Enabled
1: Always
0: Secondary PI enabled
1: Always
Default: 0
Range: 0, 1
–
<1> Unit is determined by S3-04.
<2> Upper limit is S3-02, decimal placeholder is determined by S3-03.
u
S4: Bypass Operation
No.
(Addr.
Hex)
Name LCD Display Description Values Page
S4-01
(322B)
BP Auto Transfer on
Fault Enable
BP Fault Trnsfer
0: Disabled
1: Enabled
0: No transfer after fault
1: Transfer to bypass after fault
Default: 1
Range: 0, 1
–
S4-02
(322C)
BP Energy Save Bypass
Trigger Level
BP Enrgy Sav Lvl
Delta used to determine when to switch into Energy Save Bypass.
This allows for lower frequency output values to also trigger
Energy Save Bypass functionality.
Default: 0 Hz
Min.: 0
Max.: 20
–
S4-03
(322D)
BP Energy Save Bypass
Timer
BP Enrgy Sav TMR
Sets the time in seconds that the drive should run at the specified
speed before entering Energy Save Bypass mode.
Default: 60 s
Min.: 10
Max.: 60000
–
S4-04
(322E)
BP Energy Save Bypass
Speed Increase
BP Enrgy Sav Inc
Sets the value in Hz that the drive will increase the output
frequency above E1-04 before performing an Energy Save
transfer to bypass.
Default: 6 Hz
Min.: 0
Max.: 10
–
u
S5: HOA Keypad Parameters
No.
(Addr.
Hex)
Name LCD Display Description Values Page
S5-01
(322F)
HAND Frequency
Reference Selection
HAND Fref Source
0: Operator
1: Terminals
2: d1-16
3: S5-05
4: Set by b1-01
0: HOA keypad
1: Terminals
2: d1-16
3: S5-05
4: Determined by b1-01
Default: 0
Range: 0 to 4
–
S5-02
(3230)
HAND/AUTO During
Run Selection
HAND/AUTO
@Run
0: Disabled
1: Enabled
0: Disabled
1: Enabled Default: 1
Range: 0, 1
–
S5-03
(3231)
HAND Mode PI
Selection
HAND Mode PI Sel
0: Disabled
1: Enabled
0: Disabled
1: Enabled
Default: 1
Range: 0, 1
–
S5-04
(3232)
HAND Mode Behavior
Selection
HAND BehaviorSel
0: Legacy
1: Normal
2: Normal w/
Memory
0: Legacy operation mode
1: Normal operation mode
2: Normal with memory
Note: 1. The drive will always be in AUTO mode at
power up with S5-04 = 1.
2. When S5-04 = 2, if the drive is powered down
with HAND from the HOA keypad, the drive
will power up in OFF mode.
Default: 1
Range: 0 to 2
–
S5-05
(3233)
HAND Frequency
Reference 1
HAND Freq Ref 2
Sets the frequency reference used in HAND mode when S5-01 is
set to 3.
Default: 0.00
Hz
Min.: 0.00
Max.: [E4-01]
<1>
–
B.11 S: Special Application
328
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
