Auto-Tuning for Permanent Magnet Motors
Automatically sets the V/f pattern and motor parameters E1-oo and E5-oo when a PM motor is used.
Table 4.20 Types of Auto-Tuning for Permanent Magnet Motors
Type Setting Application Conditions and Benefits
Control Mode
OLV/PM
PM Motor Parameter
Settings
T2-01 = 0
• Motor does not rotate during Auto-Tuning.
• Motor test report or motor data similar to Table 4.21 are available.
YES
Table 4.21 lists the data that must be entered for Auto-Tuning. Make sure the data is available before starting Auto-Tuning.
The necessary information is usually listed on the motor nameplate or in the motor test report provided by the motor
manufacturer. Also refer to page 122 for details on the Auto-Tuning process and selection.
Table 4.21 Auto-Tuning Input Data
Input Value Input Parameter Unit
Tuning Type (T2-01)
0
Motor Parameter
Settings
Control Mode A1-02 – 5
Motor Type T2-03 – –
Motor Rated Power T2-04 kW YES
Motor Rated Voltage T2-05 Vac YES
Motor Rated Current T2-06 A YES
Motor Rated Frequency T2-07 Hz YES
Number of Motor Poles T2-08 – YES
Stator Single-phase Resistance T2-10 Ω YES
d-Axis Inductance T2-11 mH YES
q-Axis Inductance T2-12 mH YES
Induced Voltage Constant Unit Selection
<1>
T2-13 mVs/rad (elec.) YES
Voltage Constant
<1>
<2>
T2-14 mVmin (mech.) YES
Tuning Pull-in Current T2-15 A –
T2 Tuning Start T2-18 – YES
<1> It is only necessary to input either T2-13 or T2-14. Select one and leave the other empty.
<2> Dependent upon T2-13 setting.
u
Before Auto-Tuning the Drive
Check the items below before Auto-Tuning the drive.
n
Basic Auto-Tuning Preparations
• Auto-Tuning requires the user to input data from the motor nameplate or motor test report. Make sure this data is available
before Auto-Tuning the drive.
• For best performance, the drive input supply voltage must be at least equal to or greater than the motor rated voltage.
Note: Better performance is possible when using a motor with a base voltage that is lower than the input supply voltage (20 V for 200 V class
models and 40 V for 400 V class models). This is particularly important when operating the motor above 90% of base speed, where high
torque precision is required.
• To cancel Auto-Tuning, press the OFF key on the HOA keypad.
• When using a motor contactor, make sure it is closed throughout the Auto-Tuning process.
Table 4.22 Auto-Tuning Input Data
Motor Type Auto-Tuning Type Digital Input Digital Output
Induction
Motor
Stationary Auto-Tuning for Line-to-Line Resistance
Digital input functions
are disabled.
Maintains the status at the start of Auto-Tuning
Rotational Auto-Tuning for V/f Control Functions the same as during normal operation
PM Motor PM Motor Parameter Settings Digital output functions are disabled.
4.8 Auto-Tuning
144
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
