Subchart A-2: Operation with Permanent Magnet Motors
Flowchart A-2 in Figure 4.10 describes the setup procedure for running a PM motor in Open Loop Vector Control. PM motors
can be used for more energy-efficient operation in reduced or variable torque applications.
From
Flowchart
A
Input the motor data.
(T2-01 = 0)
Run the motor without load; check the rotation direction and
operation.Verify external signal commands to the drive work as desired.
Connect the load to the motor.
Run the machine and check for desired operation.
Return to
Flowchart
A
Figure 4.10 Operation with Permanent Magnet Motors
