YASKAWA Z1000 - Altitude Derating

40°C
100%
60%
-10°C
0%
50°C
80%
IP20/NEMA 1, UL Type 1
IP00/Open-Type
External Heatsink
Figure A.6 Ambient Temperature and Installation Method Derating
u
Altitude Derating
The drive standard ratings are valid for installation altitudes up to 1000 m. For installations from 1000 m to 3000 m, the drive
rated output current must be derated for 0.2% per 100 m.
A.4 Drive Derating Data
