YASKAWA Z1000 User Manual

1.4 Drive Models and Enclosure Types
The following enclosure types are offered for Z1000 drives:
• IP20/NEMA 1, UL Type 1 enclosure models mount to an indoor wall or in an enclosure panel.
• IP00/Open-Type enclosure models are designed for installation in an enclosure panel that serves to protect personnel from
injury caused by accidentally touching live parts.
Table 1.5 describes drive enclosures and models.
Table 1.5 Drive Models and Enclosure Types
Voltage Class
Enclosure Type
IP20/NEMA 1, UL Type 1 Enclosure
<1>
Drive Model CIMR-Zo
IP00/Open-Type Enclosure
Drive Model CIMR-Zo
Three-Phase
200 V Class
2A0011F –
2A0017F –
2A0024F –
2A0031F –
2A0046F –
2A0059F –
2A0075F –
2A0088F –
2A0114F –
2A0143F –
2A0169F –
2A0211F –
2A0273F –
– 2A0343A
– 2A0396A
Three-Phase
400 V Class
4A0005F –
4A0008F –
4A0011F –
4A0014F –
4A0021F –
4A0027F –
4A0034F –
4A0040F –
4A0052F –
4A0065F –
4A0077F –
4A0096F –
4A0124F –
4A0156F –
4A0180F –
4A0240F –
4A0302F –
– 4A0361A
– 4A0414A
– 4A0480A
– 4A0590A
<1> Removing the top protective cover from an IP20/NEMA 1, UL Type 1 enclosure drive voids the NEMA Type 1 protection while maintaining IP20
conformity; removing the bottom conduit bracket voids the NEMA Type 1 protection and IP20 conformity.
1.4 Drive Models and Enclosure Types
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
29
1
Receiving

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
