Setting 0: No Action
The Run command data are kept.
Setting 1: Number of Run Commands Counter
Resets the Run command counter. The monitor U4-02 will show 0. Setting o4-13 to 1 and pressing the ENTER key erases the
counter value and returns the display to 0.
n
o4-17: Set/Reset Real Time Clock
The time setting screen will appear.
Z1000
Software
Version
No.
(Addr.
Hex)
LCD Display Name Description Values
PRG: 1012
and earlier
o4-17
(3100)
Set Time
0: Disabled
1: Enabled
Set/Reset Real Time
Clock
Sets the current date and time for the Real Time Clock.
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
PRG: 1013
and later
o4-17
(3100)
Set Time
0: — —
1: Set
2: Reset
Set/Reset Real Time
Clock
Sets the current date and time for the Real Time Clock.
0: — — No Setting
1: Real Time Clock Set
2: Real Time Clock Reset
Default: 0
Range: 0 to 2
Setting 0: — —
No Setting
Setting 1: Set
The HOA keypad shows the Clock Adjustment display. In Clock Adjustment Mode the user can adjust the Real Time Clock.
Setting 2: Reset
The Real-Time Clock data is cleared. A TIM fault will occur until o4-17 is set to 1 to set the Real Time Clock.
n
T1-01: Auto-Tuning Mode Selection
Sets the type of Auto-Tuning to be used. Refer to Auto-Tuning for Induction Motors on page 143 for details on the different
types of Auto-Tuning.
No. Name Setting Range Default
T1-01 Auto-Tuning Mode Selection 2, 3 2
Setting 2: Stationary Auto-Tuning for Line-to-Line Resistance
Setting 3: Rotational Auto-Tuning for V/f Control Energy Saving
n
T1-02: Motor Rated Power
Sets the motor rated power according to the motor nameplate value.
Note: Use the following formula to convert HP to kW: kW = HP x 0.746.
No. Name Setting Range Default
T1-02 Motor Rated Power 0.00 to 650.00 kW Determined by o2-04
n
T1-03: Motor Rated Voltage
Sets the motor rated voltage according to the motor nameplate value. Enter the voltage base speed when the motor operates
above base speed. Enter the voltage needed to operate the motor under no-load conditions at rated speed to T1-03.
No. Name Setting Range Default
T1-03 Motor Rated Voltage
0.0 to 255.0 V
<1>
200.0 V
<1>
<1> Values shown are specific to 200 V class drives. Double value for 400 V class drives.
n
T1-04: Motor Rated Current
Sets the motor rated current according to the motor nameplate value. Enter the current at the motor base speed.
No. Name Setting Range Default
T1-04 Motor Rated Current
10.0 to 300.0% of drive rated
current
Determined by
o2-04
4.13 Advanced Drive Setup Adjustments
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
193
4
Start-Up Programming
& Operation
