YASKAWA Z1000 User Manual

No. Name
User
Setting
T1-03 Motor Rated Voltage
T1-04 Motor Rated Current
T1-05 Motor Base Frequency
T1-06 Number of Motor Poles
T1-07 Motor Base Speed
T1-11 Motor Iron Loss
T2-01 PM Motor Auto-Tuning Mode Selection
T2-02 PM Motor Code Selection
T2-03 PM Motor Type
T2-04 PM Motor Rated Power
No. Name
User
Setting
T2-05 PM Motor Rated Voltage
T2-06 PM Motor Rated Current
T2-07 PM Motor Base Frequency
T2-08 Number of PM Motor Poles
T2-10 PM Motor Stator Resistance
T2-11 PM Motor d-Axis Inductance
T2-12 PM Motor q-Axis Inductance
T2-13 Induced Voltage Constant Unit Selection
T2-14 PM Motor Induced Voltage Constant
T2-15 Pull-In Current Level for PM Motor Tuning
E.3 User Setting Table
386
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
