YASKAWA Z1000 User Manual

n
Three-Phase 400 V Class
Table 3.3 Wire Gauge and Torque Specifications (Three-Phase 400 V Class)
Model Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4A0005
4A0008
4A0011
R/L1, S/L2, T/L3 14
14 to 8
M4
1.6 to 1.8
(14 to 16)
U/T1, V/T2, W/T3 14
-M, +M –
– M5
2.7 to 3.0
(24 to 27)
4A0014
R/L1, S/L2, T/L3 12
14 to 8
M4
1.6 to 1.8
(14 to 16)
U/T1, V/T2, W/T3 12
-M, +M –
– M5
2.7 to 3.0
(24 to 27)
4A0021
R/L1, S/L2, T/L3 10
14 to 8
M4
1.6 to 1.8
(14 to 16)
U/T1, V/T2, W/T3 10
-M, +M –
– M5
2.7 to 3.0
(24 to 27)
4A0027
R/L1, S/L2, T/L3 8
14 to 8
M4
1.6 to 1.8
(14 to 16)
U/T1, V/T2, W/T3 8
-M, +M –
– M5
2.7 to 3.0
(24 to 27)
4A0034
<1>
R/L1, S/L2, T/L3 8
10 to 4 M5
2.7 to 3.0
(24 to 27)
U/T1, V/T2, W/T3 8
-M, +M –
–
4A0040
4A0052ooB
<1>
R/L1, S/L2, T/L3 8
10 to 4 M5
2.7 to 3.0
(24 to 27)
U/T1, V/T2, W/T3 8
-M, +M –
–
4A0052ooA
<1>
R/L1, S/L2, T/L3 6
8 to 2/0 M8
5.4 to 6.0
(48 to 53)
U/T1, V/T2, W/T3 6
-M, +M –
–
4A0065
<1>
R/L1, S/L2, T/L3 4
8 to 2/0 M8
5.4 to 6.0
(48 to 53)
U/T1, V/T2, W/T3 4
-M, +M –
–
4A0077
<1>
R/L1, S/L2, T/L3 3
8 to 2/0 M8
5.4 to 6.0
(48 to 53)
U/T1, V/T2, W/T3 3
-M, +M –
–
4A0096
<1>
R/L1, S/L2, T/L3 1
8 to 2/0 M8
5.4 to 6.0
(48 to 53)
U/T1, V/T2, W/T3 1
-M, +M –
–
4A0124
<1>
R/L1, S/L2, T/L3 2/0
8 to 2/0 M8
5.4 to 6.0
(48 to 53)
U/T1, V/T2, W/T3 2/0
-M, +M –
–
3.8 Main Circuit Wiring
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
85
3
Electrical Installation

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
