YOKOGAWA AQ7260 OTDR User Manual

Chapter 3 PERFORMING MEASUREMENTS
3-86
1. Press [MODE] to locate the cursor to “MARKER” (“MARKER” is highlighted).
2. Locate the cursor near the desired event by turning the rotary knob.
For the method of moving the cursor, refer to page 3-64.
3. Enlarge the trace.
For the method of enlarging the trace, refer to page 3-66.
4. Locate the cursor to the event by turning the rotary knob.
5. Press [F1] (
1
).
Marker
1
will appear at the cursor position.
Distance from the origin to
1
Refer
Refer
