Chapter 8 USING OPTIONS AND EXTERNAL DEVICES
8-60
EDR
The numeric part for each item is left aligned and displayed, with the unit part at the fixed
position.
Items are displayed in the order “event No.”, “distance”, “splice loss”, “return loss”,
“cumulative loss”, “dB/km” and “event type”.
123456789101112131415161718192021222324252627282930
XXX , SXXXX . XXXXXTT , SXX . XXXDB, SX
31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
X . XXXDB ,SXX . XXXDB , SXX . XXXDB/ TT
61 62 63 64 65 66
,SX CRLF
SPDR
EDR is output in the event order, separated by a delimiter.
It is output for each event sequentially, finally followed by the END event. The format for
END event is given below.
For the format for each event, refer to “EDR” since it is the same as that for EDR.
In the case of RS-232C: All the events are output at once, with each event separated by a
comma (,).
In the case of GP-IB: Created by dividing the return value for each item using the
delimiters (CR and LF), and outputting the items one after
another.
123456789101112131415161718192021222324252627282930
END,SXXXX . XXXXXTT , SX
31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
X . XXXDB,SXX .XXXDB, SXX . XXXDB/ TT
61 62 63 64 65 66
,SX CRLF
SDR
Data is output in the order of “interval distance”, “interval loss” and “interval return loss”.
The numeric part is left aligned and displayed, with the unit part at the fixed position.
123456789101112131415161718192021222324252627282930
SXXXX . XXXXXTT , SXX . XXXDB,SXX.XX
31 32 33 34 35
XDBCRLF
IDER
Data is output in the order of “company name”, “instrument’s model name (S/N)”, “optical
module’s model name (S/N)” and “software version”, with each item separated by a
comma (,).
