YOKOGAWA UT55A User Manual

7-4
IM 05P01C31-01EN
Parameter
symbol
Name
Display
level
Setting range Menusymbol
SL
(Scaling)
MinimumvalueofPV
input scale
EASY
-19999 to 30000, (SL<SH),
|
SH-
SL|≤30000
PV
Minimum value of RSP
remote input range
EASY RSP
Minimum value of AIN2
aux. analog input scale
EASY AIN2
Minimum value of AIN4
aux. analog input scale
EASY AIN4
Note 1: For remote input with the optional suffix code /DR, setting range for RSP remote input type
issameasthatforPVinputtype.
Note 2: When each parameter is displayed, the terminal area (E1 to E4) is displayed on Group
display according to the suffix code and optional suffix code.
IN, UNIT, RH, and RL described above are the parameters to be used for processing
before the input ladder calculation program.
The following parameters are used for processing after the input ladder calculation
program.
Parameter
symbol
Name
Display
level
Setting range Menusymbol
P.UNI ControlPVinputunit
STD
-: No unit
C: Degree Celsius
-: No unit
- -: No unit
- - -: No unit
F: Degree Fahrenheit
MPV
P.DP
ControlPVinput
decimal point position
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
P.RH
Maximum value of
controlPVinput
range
-19999 to 30000, (P.RL<P.RH),
|P.RH-P.RL|≤30000
P.RL
Minimum value of
controlPVinput
range
Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
7.1SettingFunctionsofPVInput,RemoteInput,andAuxiliaryAnalogInput
