YOKOGAWA UT55A User Manual

7-11
IM 05P01C31-01EN
Input(PV,Remote,andAuxiliaryAnalog)Functions
Setting Details
Parameter
symbol
Name Displaylevel Setting range Menusymbol
PYS
10-segment
linearizer
selection
Group 1, 2: STD
Group 3, 4: PRO
OFF: Disable
PV:PV
analoginput
RSP: RSP analog input
AIN2: AIN2 analog input
AIN4: AIN4 analog input
PVIN:PVinput
OUT: OUT analog output
OUT2: OUT2 analog output
RET: RET analog output
PYS1
PYS2
PYS3
PYS4
A1 to A11
10-segment
linearizer
input
Group 1, 2: STD
Group 3, 4: PRO
-66.7to105.0%ofinputrange
(EU)
Outputlinearizer:-5.0to105.0%
B1 to B11
10-segment
linearizer
output
Group 1, 2: STD
Group 3, 4: PRO
10-segmentlinearizerbias:
-66.7
to105.0%ofinputrangespan
(EUS)
10-segmentlinearizer
approximation:-66.7to105.0%
of input range (EU)
Outputlinearizer:-5.0to105.0%
PMD
10-segment
linearizer
mode
Group 1, 2: STD
Group 3, 4: PRO
0:10-segmentlinearizer
bias
1:10-segmentlinearizer
approximation
Note1: When each parameter is displayed, the group number (1 to 4) is displayed on Group display.
Parameters are set in the following order.
(1) PYS:Specifieswherethe10-segmentlinearizerfunctionisused.
SetpointsPV,
RSP,AIN2,andAIN4functionbeforetheinputladdercalculation
section.
SetpointPVINfunctions
aftertheinputladdercalculationsection.
► Wherethe10-segmentlinearizerfunctionisused;Functionblockdiagramsin8.1Setting
Control Mode (CTLM)
(2) PMD:Specifieswhethertouseitasa10-segmentlinearizerbiasora10-segment
linearizerapproximation.
(3) A1toA11,B1toB11:Setsthe10-segmentlinearizerinputand10-segmentlinearizer
output.
For the input range and input range span, the range varies depending on where the
10-segmentlinearizeris
used.
 PVinputandPVanaloginput:PVinputrangeorPVinputrangespan
RSP analog input: RSP remote input range or RSP remote input range span
AIN2 auxiliary analog input: AIN2 auxiliary analog input range or AIN2 auxiliary
analog input range span
AIN4 auxiliary analog input: AIN4 auxiliary analog input range or AIN4 auxiliary
analog input range span
Note
• Setthe10-segmentlinearizersothatitincreasesmonotonically.
• Ifthesamesetpointissetforthetwoormoreparametersof10-segmentlinearizerselection
(PYS), a smaller group number is used.
7
7.1SettingFunctionsofPVInput,RemoteInput,andAuxiliaryAnalogInput
