YOKOGAWA UT55A User Manual

8-77
IM 05P01C31-01EN
Control Functions
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
CNT Control type EASY
PID: PID control
ONOF: ON/OFF control (1 point of
hysteresis)
ONOF2: ON/OFF control (2 points
of hysteresis)
2P2L: Two-position two-level
control
H/C: Heating/cooling control
S-PI: Sample PI control
BATCH: Batch PID control
FFPID: Feedforward control
CTL
HYS
Hysteresis
(in ON/OFF
control, Position
proportional
control, or Two-
position two-level
control)
Heating-side
ON/OFF control
hysteresis (in
Heating/cooling
control)
EASY
In ON/OFF control or Two-position
two-levelcontrol:0.0to100.0%of
PVinputrangespan(EUS)
In Heating/cooling control or
Position proportional control: 0.0
to100.0%
PID
HYSc
Cooling-side
ON/OFF control
hysteresis
EASY 0.0to100.0%
DB
Output dead band
(in Heating/cooling
control or Position
proportional
control)
EASY
In Heating/cooling control: -100.0
to50.0%
In
Position proportional control: 1.0
to10.0%
PIDN
PID number
selection
EASY 1 to 8 SP
PIDG.
Number of PID
groups
STD 1 to 8 CTL
Note1: The PID number (1 to 8, or R) is displayed on Group display while the parameter HYS,
HYSc, or DB is displayed.
Note2: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
Note
When changing the setpoint of the parameter PIDG., if the setpoint of the parameter PIDN
which belongs to the SP menu is larger than that of the parameter PIDG., the PIDN setpoint is
changed to the PIDG. setpoint.
8
8.2SettingControlType(CNT)
