Control Functions
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
CNT Control type EASY
PID: PID control
ONOF: ON/OFF control (1 point of
hysteresis)
ONOF2: ON/OFF control (2 points
of hysteresis)
2P2L: Two-position two-level
control
H/C: Heating/cooling control
S-PI: Sample PI control
BATCH: Batch PID control
FFPID: Feedforward control
CTL
SP Target setpoint EASY
0.0to100.0%ofPVinputrange
(EU) (Setting range: SPL to SPH)
SP
SUB
Sub-target setpoint
(in Two-position
two-level control)
EASY
Set the offset from SP.
-100.0to100.0%ofPVinput
range span (EUS)
HYS
Hysteresis
(in ON/OFF
control, Position
proportional
control, or Two-
position two-level
control)
Heating-side
ON/OFF control
hysteresis (in
Heating/cooling
control)
EASY
In ON/OFF control or Two-position
two-levelcontrol:0.0
to100.0%of
PVinputrangespan(EUS)
In Heating/cooling control or
Position proportional control: 0.0
to100.0%
PID
SU.HY
Sub-hysteresis (in
Two-position two-
level control)
EASY
0.0to100.0%ofPVinputrange
span (EUS)
DR
Direct/reverse
action switch
STD
RVS:Reverse
action
DIR: Direct action
SU.DR
Sub-direct/reverse
action switch (in
Two-position two-
level control)
STD
PIDN
PID number
selection
EASY 1 to 8 SP
PIDG.
Number of PID
groups
STD 1 to 8 CTL
Note1: The PID number (1 to 8, R) is displayed on Group display while the parameter SP, SUB,
HYS, SU.HY, DR, or SU.DR is displayed.
Note
When changing the setpoint of the parameter PIDG., if the setpoint of the parameter PIDN
which belongs to the SP menu is larger than that of the parameter PIDG., the PIDN setpoint is
changed to the PIDG. setpoint.
8
8.2SettingControlType(CNT)
