YOKOGAWA UT55A User Manual

8-84
IM 05P01C31-01EN
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
CNT Control type EASY
PID: PID control
ONOF: ON/OFF control (1 point of
hysteresis)
ONOF2: ON/OFF control (2 points
of hysteresis)
2P2L: Two-position two-level
control
H/C: Heating/cooling control
S-PI: Sample PI control
BATCH: Batch PID control
FFPID: Feedforward controll
CTL
P Proportional band EASY
0.0to999.9%
When0.0%isset,itoperatesas
0.1%.
PID
I Integral time EASY
OFF: Disable
1 to 6000 s
D Derivative time EASY
OFF: Disable
1 to 6000 s
PIDN
PID number
selection
EASY 1 to 8 SP
PIDG.
Number of PID
groups
STD 1 to 8 CTL
BD
Batch PID
deviation setpoint
PRO
0.0to100.0%ofPVinputrange
span (EUS)
TUNE
BB Batch PID bias PRO 0.0to100.0%
BL
Batch PID lock-up
width
PRO
0.0to100.0%
ofPVinputrange
span (EUS)
Note
When changing the setpoint of the parameter PIDG., if the setpoint of the parameter PIDN
which belongs to the SP menu is larger than that of the parameter PIDG., the PIDN setpoint is
changed to the PIDG. setpoint.
8.2SettingControlType(CNT)
