YOKOGAWA UT55A User Manual

12-9
IM 05P01C31-01EN
ContactInput/OutputFunctions
12
UT55A(Standardmodel)DIandSetpoint(Irelaynumber)
DI equipped as standard
DIsymbol Setpoint
DI1 5025
DI2 5026
DI3 5027
Additional DI
DIsymbol Setpoint DIsymbol Setpoint DIsymbol Setpoint DIsymbol Setpoint
DI11 5041 – – DI31 5073 DI41 5089
DI12 5042 – – DI32 5074 DI42 5090
DI13 5043 – – DI33 5075 DI43 5091
DI14 5044 – – DI34 5076 DI44 5092
DI15 5045 – – DI35 5077 DI45 5093
DI16 5046 DI26 5062 – – DI46 5094
DI16canbeusedwhenthesuffixcode:Type2=1,2,4,5,or7,andwithouttheoptionalsuffixcode/DR.
UT52A(Standardmodel)DIandSetpoint(Irelaynumber)
DI equipped as standard
DIsymbol Setpoint
DI1 5025
DI2 5026
DI3 5027
Additional DI
DIsymbol Setpoint
DI11 5041
DI12 5042
DI16 5046
DI16canbeusedwhenthesuffixcode:Type2=1,2,or3,andwithouttheoptionalsuffixcode/DR.
UT55A/UT52A(Detailedmodel)DIandSetpoint(Irelaynumber)
DI equipped as standard
DIsymbol Setpoint
DI1 5025
DI2 5026
DI3 5027
Additional DI
Option/X1 Option/X2 Option/X3 Option/X4
DIsymbol Setpoint DIsymbol Setpoint DIsymbol Setpoint DIsymbol Setpoint
DI11 5041 DI21 5057 DI31 5073 DI41 5089
DI12 5042 DI22 5058 DI32 5074 DI42 5090
DI13 5043 DI23 5059 DI33 5075 DI43 5091
DI14 5044 DI24 5060 DI34 5076 DI44 5092
DI15 5045 DI25 5061 DI35 5077 DI45 5093
Additional DI
Option/R1or
/RCH1
Option/A2
Option/A4or
/AC4
DIsymbol Setpoint DIsymbol Setpoint DIsymbol Setpoint
DI16
5046 DI26 5062 DI46 5094
12.1 Setting Contact Input Function
