ContactInput/OutputFunctions
12
Error Status
Setpoint Function
Contact status
ON OFF
4065 PVinputADC
error
Error occurs Normal
4066
RSP input (E1-terminal area)
ADC error
4067
AIN2 input (E2-terminal area)
ADC error
4069
AIN4 input (E4-terminal area)
ADC error
4073 PVinputburnouterror
4074
RSP input (E1-terminal area)
burnout error
4075
AIN2 input (E2-terminal area)
burnout error
4077
AIN4 input (E4-terminal area)
burnout error
4070 PVinputRJC error
4071
RSP input RJC error
4081
Feedback resistance/current
burnout
4082
Automatic valve position
adjustmenterror
4097 PVinputburnout
error(Loop1)
4098 RSP input burnout error (Loop 1)
4101 PVinputover-scale(Loop 1)
4102 PVinputunder-scale(Loop 1)
4111 Auto-tuning time out (Loop 1)
4113 PVinputburnout(Loop2)
4114 RSP input burnout (Loop 2)
4117 PVinputover-scale(Loop2)
4118 PVinputunder-scale(Loop2)
4127 Auto-tuning time out (Loop 2)
12.2SettingContactOutputFunction
