YOKOGAWA UT55A User Manual

13-29
IM 05P01C31-01EN
Display, Key, and Security Functions
ParameterX200
Displayed digit bit Description
1st digit
0 DI21 status (0: OFF, 1: ON)
1 DI22 status (0: OFF, 1: ON)
2 DI23 status (0: OFF, 1: ON)
3 DI24 status (0: OFF, 1: ON)
2nd digit
4 DI25 status (0: OFF, 1: ON)
5 DI26 status (0: OFF, 1: ON)
6 –
7 –
3rd digit
8 –
9 –
10 –
11 –
4th digit
12 –
13 –
14 –
15 –
Parameter
X300
Displayed digit bit Description
1st digit
0 DI31 status (0: OFF, 1: ON)
1 DI32 status (0: OFF, 1: ON)
2 DI33 status (0: OFF, 1: ON)
3 DI34 status (0: OFF, 1: ON)
2nd digit
4 DI35 status (0: OFF, 1: ON)
5 –
6 –
7 –
3rd digit
8 –
9 –
10 –
11 –
4th digit
12 –
13 –
14 –
15 –
Parameter
X400
Displayed digit bit Description
1st digit
0 DI41 status (0: OFF, 1: ON)
1 DI42 status (0: OFF, 1: ON)
2 DI43 status (0: OFF, 1: ON)
3 DI44 status (0: OFF, 1: ON)
2nd digit
4 DI45 status (0: OFF, 1: ON)
5 DI46 status (0: OFF, 1: ON)
6 –
7 –
3rd digit
8 –
9 –
10 –
11 –
4th digit
12 –
13 –
14 –
15 –
13
13.4ConfirmationofKeyandI/OConditionandVersion
