YOKOGAWA UT55A User Manual

17-21
IM 05P01C31-01EN
Installation and Wiring
17
AdditionalContactOutputAccordingtotheUT55ASuffixCodes
(ForStandardmodel)UT55Asufxcode:
Type2=6
(ForDetailedmodel)UT55Aoptionalsufx
code: /Y1
(ForStandardmodel)UT55Asufxcodes:
Type2=1,3,5or6
(ForDetailedmodel)UT55Aoptionalsufx
codes: /Y2
Transistor contact rating: 24 V DC, 50 mA
DO12
DO11
DO13
DO14
DO15
COM
301
302
303
304
305
306
DO
Transistor contact rating: 24 V DC, 50 mA
DO22
DO21
DO23
DO24
DO25
COM
307
308
309
310
311
312
DO
Factory default: Function is not assigned to the additional contact outputs (DO11 to
DO15).
(ForStandardmodel)UT55Asufxcode:
Type2=6
(ForDetailedmodel)UT55Aoptionalsufx
code: /Y3
(ForDetailedmodel)UT55Aoptionalsufx
code: /Y4
Transistor contact rating: 24 V DC, 50 mA
DO32
DO31
DO33
DO34
DO35
COM
407
408
409
410
411
412
DO
Transistor contact rating: 24 V DC, 50 mA
DO42
DO41
DO43
DO44
DO45
COM
501
502
503
504
505
506
DO
Factory default: Function is not assigned to the additional contact outputs.
► Contactoutputfunctionregistration:12.2SettingContactOutputFunction
17.4 Wiring
