YOKOGAWA UT55A User Manual

17-22
IM 05P01C31-01EN
(ForDetailedmodel)UT55Aoptionalsufx
code: /W1
(ForDetailedmodel)UT55Aoptionalsufx
code: /W2
Transistor contact rating: 24 V DC, 50 mA
DO12
DO11
COM
304
305
306
DO
Transistor contact rating: 24 V DC, 50 mA
DO22
DO21
COM
310
311
312
DO
(ForDetailedmodel)UT55Aoptionalsufx
code: /W3
(ForDetailedmodel)UT55Aoptionalsufx
code: /W4
Transistor contact rating: 24 V DC, 50 mA
DO32
DO31
COM
410
411
412
DO
Transistor contact rating: 24 V DC, 50 mA
DO42
DO41
COM
504
505
506
DO
AdditionalContactOutputAccordingtotheUT52AOptionalSuffixCodes
(ForDetailedmodel)UT52Aoptionalsufxcode:/Y1
Transistor contact rating: 24 V DC, 50 mA
DO12
DO11
DO13
DO14
DO15
COM
301
302
303
304
305
306
DO
Factory default: Function is not assigned to the additional contact outputs.
► Contact output function registration: 12.2 Setting Contact Output Function
(ForStandardmodel)UT52Asufxcode:Type2=3
(ForDetailedmodel)UT52Aoptionalsufxcode:/W1
Transistor contact rating: 24 V DC, 50 mA
DO12
DO11
COM
304
305
306
DO
17.4 Wiring
