18-24
IM 05P01C31-01EN
OutputSettingMenu(Menu:OUT)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
OT
Output type
selection
EASY
Control output or Heating-side
control output (Lower two digits)
00: OFF
01: OUT terminals (voltage pulse)
02: OUT terminals (current)
03: OUT terminals (relay/triac)
04: OUT2 terminals (voltage pulse)
05: OUT2 terminals (current)
06: OUT2 terminals (relay/triac)
Cooling-side control output (Upper
two digits)
00: OFF
01: OUT terminals (voltage pulse)
02: OUT terminals (current)
03: OUT terminals (relay/triac)
04: OUT2 terminals (voltage pulse)
05: OUT2 terminals (current)
06: OUT2 terminals (relay/triac)
Standard type:
00.03
Heating/
cooling type:
06.03
CT
Control output cycle
time
Heating-side control
output cycle time
(in Heating/cooling
control)
EASY
0.5 to 1000.0 s
30.0 s
CTc
Cooling-side control
output cycle time
EASY 30.0 s
V.AT
Automatic valve
position
adjustment
EASY
OFF:Stop
automaticadjustment
ON:Startautomaticadjustment
OFF
V.RS
Valveposition
setting reset
EASY
SettingV.RS
toONresetsthe
valveadjustmentsettingsand
causestheindication“V.RS”to
blink.
OFF
V.L
Fully-closed valve
position setting
EASY
Pressing the SET/ENTER key
with valve position set to the fully-
closed position by Down arrow
keycausesthe
adjustedvalueto
bestored.WhenV.Ladjustmentis
complete,V.Lstopsblinking.
-
V.H
Fully-open valve
position setting
EASY
Pressing the SET/ENTER key
with valve position set to the fully-
opened position by Up arrow key
causestheadjusted
valuetobe
stored.WhenV.Hadjustmentis
complete,V.Hstopsblinking.
-
TR.T Valvetravelingtime STD 5 to 300 s 60 s
V.MOD
Valveadjusting
mode
STD
0:
Valve
positionfeedbacktype
1:Valvepositionfeedbacktype
(moves to the estimating type if
a feedback input error or break
occurs.)
2:Valvepositionestimatingtype
0
18.2ListofParameters
