YOKOGAWA UT55A User Manual

18-27
IM 05P01C31-01EN
Parameters
18
OutputSettingMenu(Menu:OUT)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
OU.H
100%segmental
point of OUT
current output
PRO
-100.0to200.0%
100.0%
OU.L
0%
segmentalpoint
of OUT current
output
PRO 0.0%
OU2.H
100%segmental
point of OUT2
current output
PRO 100.0%
OU2.L
0%segmentalpoint
of OUT2 current
output
PRO 0.0%
RET.H
100%segmental
point of RET current
output
PRO 100.0%
RET.L
0%segmentalpoint
of RET current
output
PRO 0.0%
OU.A
OUT current output
range
PRO
4-20: 4 to 20 mA
0-20: 0 to 20 mA
20-4: 20 to 4 mA
20-0: 20 to 0 mA
4-20
OU2.A
OUT2 current
output range
PRO 4-20
RET.A
RET current output
range
PRO 4-20
HeaterBreakAlarmSettingMenu(Menu:HBA)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
HB1.S,
HB2.S
Heater break
alarm-1, -2 function
selection
EASY
0: Heater current measurement
1: Heater break alarm
1
HB1, HB2
Heater break
alarm-1, -2 current
setpoint
EASY OFF, 0.1 to 300.0 Arms OFF
CT1.T, CT2.T
CT1, CT2 coil
winding number
ratio
EASY 1 to 3300 800
HDN1, HDN2
Heater break
alarm-1, -2 On-
delay timer
STD
0.00 to 99.59 (minute.second)
0.00
HDF1, HDF2
Heater break
alarm-1, -2 Off-
delay timer
PRO 0.00
HB1.D,
HB2.D
Heater break
alarm-1, -2 contact
type
PRO
CLS: When the event occurs, the
contact is closed.
OPN: When the event occurs, the
contact is opened.
CLS
18.2ListofParameters
