YOKOGAWA UT55A User Manual

18-26
IM 05P01C31-01EN
OutputSettingMenu(Menu:OUT)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
O1RS
Retransmission
output type of OUT
current output
STD Same as RTS OFF
O1RH
Maximum value
of retransmission
output scale of OUT
current output
STD
When
O1RS=
PV1,SP1,PV2,
SP2,TSP1,TSP2,PV,RSP,AIN2,
or AIN4,
O1RL + 1 digit to 30000
-19999 to O1RH - 1 digit
Decimal point position:
WhenO1RS=PV1,SP1,orTSP1,
decimal point position is same
asthatofPVinput.
WhenO1RS=PV2,SP2,orTSP2,
decimal point position is same
as that of RSP input.
WhenO1RS=PV,decimalpoint
positionissameasthatofPV
input scale.
WhenO1RS=RSP,decimalpoint
position is same as that of RSP
input scale.
WhenO1RS=AIN2,decimalpoint
position is same as that of AIN2
scale.
WhenO1RS=AIN4,decimalpoint
position is same as that of AIN4
scale.
-
O1RL
Minimum value
of retransmission
output scale of OUT
current output
STD -
O2RS
Retransmission
output type of OUT2
current output
STD Same as RTS OFF
O2RH
Maximum value
of retransmission
output scale of
OUT2 current
output
STD
When
O2RS=
PV1,SP1,PV2,
SP2,TSP1,TSP2,PV,RSP,AIN2,
or AIN4,
O2RL + 1 digit to 30000
-19999 to O2RH - 1 digit
Decimal point position:
WhenO2RS=PV1,SP1,orTSP1,
decimal point position is same
asthatofPVinput.
WhenO2RS=PV2,SP2,orTSP2,
decimal point position is same
as that of RSP input.
WhenO2RS=PV,decimalpoint
positionissameasthatofPV
input scale.
WhenO2RS=RSP,decimalpoint
position is same as that of RSP
input scale.
WhenO2RS=AIN2,decimalpoint
position is same as that of AIN2
scale.
WhenO2RS=AIN4,decimalpoint
position is same as that of AIN4
scale.
-
O2RL
Minimum value
of retransmission
output scale of
OUT2 current
output
STD -
18.2ListofParameters
