18-33
IM 05P01C31-01EN
Parameters
18
DisplayFunctionSettingMenu(Menu:DISP)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
BDV
Bar-graph
deviation display
band
STD
0.0to100.0%
ofPVinputrangespan
(EUS)
10.0%ofPV
input range
span
EV1to
EV8
EV1toEV8
display condition
registration
PRO
Setting range: 4001 to 6304
OFF: Disable
4321: Link to alarm 1 (Lit when the alarm occurs)
4322: Link to alarm 2 (Lit when the alarm occurs)
4323: Link to alarm 3 (Lit when the alarm occurs)
4325: Link to alarm 4 (Lit when the alarm occurs)
4326: Link to alarm 5 (Lit when the alarm occurs)
4327: Link to alarm 6 (Lit when the alarm occurs)
4329: Link to alarm 7 (Lit when the alarm occurs)
4330: Link to alarm 8 (Lit when the alarm occurs)
4337: Link to Loop-2 alarm 1 (Lit when the alarm
occurs)
4338: Link to Loop-2 alarm 2 (Lit when the alarm
occurs)
4339: Link to Loop-2 alarm 3 (Lit when the alarm
occurs)
4341: Link to Loop-2 alarm 4 (Lit when the alarm
occurs)
4342: Link to Loop-2 alarm 5 (Lit when the alarm
occurs)
4343: Link to Loop-2 alarm 6 (Lit when the alarm
occurs)
4345: Link to Loop-2 alarm 7 (Lit when the alarm
occurs)
4346: Link to Loop-2 alarm 8 (Lit when the alarm
occurs)
4529: Heater break alarm 1 (Lit when the alarm
occurs)
4530: Heater break alarm 2 (Lit when the alarm
occurs)
5025 to 5027: Link to DI1-DI3 (Lit when the
contact is closed)
5041 to 5046: Link to DI11-DI16 (E1-terminal
area) (Lit when the contact is closed)
5057 to 5062: Link to DI21-DI26 (E2-terminal
area) (Lit when the contact is closed)
5073 to 5077: Link to DI31-DI35 (E3-terminal
area) (Lit when the contact is closed)
5089 to 5094: Link to DI41-DI46 (E4-terminal
area) (Lit when the contact is closed)
5153 to 5155: Link to AL1-AL3 (Lit when the
contact is closed)
5169 to 5173: Link to DO11-DO15 (E1-terminal
area) (Lit when the contact is closed)
5185 to 5189: Link to DO21-DO25 (E2-terminal
area) (Lit when the contact is closed)
5201 to 5205: Link to DO31-DO35 (E3-terminal
area) (Lit when the contact is closed)
5217 to 5221: Link to DO41-DO45 (E4-terminal
area) (Lit when the contact is closed)
For other functions, see the UTAdvanced Series
Communication Interface User’s Manual.
Loop 1
EV1:4321
EV2:4322
EV3:4323
EV4:4325
EV5:4326
EV6:4327
EV7:4329
EV8:4330
Loop 2
EV1:4337
EV2:4338
EV3:4339
EV4:4341
EV5:4342
EV6:4343
EV7:4345
EV8:4346
In Cascade control, the following parameters are also displayed for secondary loop. (the LP2 lamp
is lit)
•Parameter:BDV
,EV1toEV8
18.2ListofParameters
