18-35
IM 05P01C31-01EN
Parameters
18
DisplayFunctionSettingMenu(Menu:DISP)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
OP.JP
Autoreturn to
operation display
PRO
Automatically returned to the
Operation Display when there has
been no keystroke operation for 5
minutes.
OFF, ON
ON
MLSD
Leastsignicant
digital
maskof
PV
display
STD
OFF:Withleastsignicantdigit
ON:Withoutleastsignicantdigit
OFF
SELECTDisplaySettingMenu(Menu:CSEL)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
CS1 to CS5
SELECT Display-1
to -5registration
STD
OFF, 2301 to 5000
OFF
CS10 to
CS19
SELECT
parameter-10 to -19
registration
PRO OFF
KeyLockSettingMenu(Menu:KLOC)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
U.SP SP Display lock PRO
OFF: Display
ON: Nondisplay
OFF
U.OUT OUT Display lock PRO
OFF
(Cascade control: ON)
U.HCO
Heating/cooling
OUT Display lock
PRO OFF
U.VP
ValvePosition
Display lock
PRO OFF
U.MV
Position
Proportional
Computation Output
Display lock
PRO ON
U.PID
PID Number
Display lock
PRO ON
U.HC
Heater Break Alarm
Current
Value
Display lock
PRO OFF
U.PV1
PV2/PV1Displaylock
PRO OFF
U.PV2
PV1/PV2Displaylock
PRO OFF
U.PV
PVAnalogInput
Display lock
PRO
ON
(Loopcontrol
withPV
switching and Loop
controlwithPVauto-
selector: OFF)
U.RSP
RSP Analog Input
Display lock
PRO
U.AI2
AIN2 Analog Input
Display lock
PRO
ON
(Loopcontrolwith
PV
auto-selector: OFF)
U.AI4
AIN4 Analog Input
Display lock
PRO
COM.W
Communication
write enable/disable
STD OFF: Enable, ON: Disable OFF
DATA
Front panel
parameter data key
lock
STD
OFF: Unlock
ON: Lock
OFF
A/M
Front panel A/M key lock
STD OFF
The following parameters are also displayed for secondary loop. (the LP2 lamp is lit)
• Parameter: U.SP, U.OUT, U.PID
18.2ListofParameters
