YOKOGAWA UT55A User Manual

18-40
IM 05P01C31-01EN
AL1-AL3FunctionRegistrationMenu(Menu:ALM)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
AL1.S
AL1 function
selection
STD
Set an I relay number.
Setting range: 4001 to 6000
No function: OFF
Alarm 1: 4353
Alarm 2: 4354
Alarm 3: 4355
Alarm 4: 4357
Alarm 5: 4358
Alarm 6: 4359
Alarm 7: 4361
Alarm 8: 4362
AUTO (ON ) / MAN (OFF) status: 4193
REM (ON) / LCL (OFF) status: 4194
STOP (ON) / RUN (OFF) status: 4195
Output tracking (ON) switching signal: 4201
FAIL (Normally ON) output: 4256
4353
AL2.S
AL2 function
selection
STD 4354
AL3.S
AL3 function
selection
STD 4355
OR.S
OUT relay function
selection
STD OFF
OR2.S
OUT2 relay function
selection
STD OFF
AL1.D AL1 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
0
AL2.D AL2 contact type PRO 0
AL3.D AL3 contact type PRO 0
OR.D
OUT relay contact
type
PRO 0
OR2.D
OUT2 relay contact
type
PRO 0
DOSettingMenu(Menu:DO)(E1toE4terminalarea)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
DO1.S
DOn1 function
selection
STD
Same as AL1.S.
Initial value of E1 and E3 teminal
area
All DO settings are OFF.
Initial value of E2 terminal area
DO1.S: 4357, DO2.S: 4358,
DO3.S: 4359, DO4.S: 4361,
DO5.S: 4362
See left
DO2.S
DOn2 function
selection
STD See left
DO3.S
DOn3 function
selection
STD See left
DO4.S
DOn4 function
selection
STD See left
DO5.S
DOn5 function
selection
STD See left
DO1.D DOn1 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
0
DO2.D DOn2 contact type PRO 0
DO3.D DOn3 contact type PRO 0
DO4.D DOn4 contact type PRO 0
DO5.D DOn5 contact type PRO 0
n: Terminal area number (1 to 4)
18.2ListofParameters
