MonitoringandControlofRegularOperations

OperationDisplayinAUTOandMANModes

“OUT” is displayed on Symbol display and “Output value” is displayed on Data display in

MAN mode. (The OUT Display is shown.)

Sub-setting-side OUT Display is shown in Two-position two-level control.

SP Display is shown in AUTO mode.

OperationDisplayinAUTOandMANModesinHeating/coolingControl

In MAN mode, the Display is as follows. Symbol “C” represents the cooling side and “H”

represents the heating side. The value on the right of each symbol is the output value.

LampStatus

Status MANlamp

Automatic operation (AUTO) Unlit

Manual operation (MAN) Lit

6.7SwitchingOperationModes
