6 - 16 DS4308/DS4308P Digital Scanner Product Reference Guide

USB Polling Interval (continued)

USB Fast HID

This option transmits

USB HID

data at a faster rate.

6 msec

7 msec

8 msec

9 msec

*Enable

Disable
