11 - 82 DS4308/DS4308P Digital Scanner Product Reference Guide

Han Xin

Parameter # 1167

(SSI #

F8h 04h 8Fh)

To enable or disable Han Xin, scan the appropriate bar code below.

Han Xin Inverse

Parameter # 1168

(SSI #

F8h 04h 90h)

Select a Han Xin inverse decoder setting:

•

Regular Only - the decoder decodes Han Xin bar codes with normal reflectance only.

•

Inverse Only - the decoder decodes Han Xin bar codes with inverse reflectance only.

•

Inverse Autodetect - the decoder decodes both regular and inverse Han Xin bar codes.

Enable Han Xin

(1)

*Disable Han Xin

(0)

*Regular

(0)

Inverse Only

(1)

Inverse Autodetect

(2)
